JPN680

JPN680

Made in Japan

Download Full Datasheet JPN680-Premium-Wax-1.pdf

THERMAL TRANSFER RIBBON Premium Wax

JPN680 Premium Wax Ribbon

A premium wax ribbon bridging the gap between wax and wax-resin, delivering exceptional smudge and heat resistance for harsh environments while maintaining cost-efficiency.

• Superior heat and smudge resistance for demanding environments
• High-speed printing up to 10 IPS with deep black density
• Excellent performance in cold storage and outdoor conditions
• Outstanding edge definition for crisp, scannable barcodes
• Versatile on coated, uncoated, and some synthetic labels

Ink Type Premium Wax

Max Speed 10 IPS

Length 300 m

Core Size 1″ / 0.5″

Width Range 40–220 mm

Backcoat Anti-static

Recommended Substrates

Coated Paper Uncoated Paper Synthetics Cold Storage

Typical Applications

Cold Storage

Shipping Labels

Product ID

Inventory

Compatible Printers

Zebra Sato TSC Datamax Intermec Honeywell Godex + More

Quantity (rolls):

− +

Enter quantity and request a quote for pricing.

Request Quote Spec Sheet

View Full Specifications

General Information

Product Code	JPN680
Ink Type	Premium Wax (High-Performance Wax)
Color	Black
Origin	Made in Japan

Ribbon Specifications

Width Available	40, 50, 60, 80, 90, 100, 110, 130, 150, 160, 170, 220 mm
Length	300 m
Core Size	1 inch (25.4 mm) / 0.5 inch (12.7 mm)
Winding Direction	Coated Side Out (CSO) / Coated Side In (CSI)
Ink Side	Outside (standard) / Inside (available on request)

Print Performance

Max Print Speed	10 IPS (254 mm/s)
Recommended Speed	2–8 IPS for optimal quality
Print Quality	Deep black density with sharp edge definition
Heat Resistance	High — withstands elevated temperatures better than standard wax
Static Control	Anti-static backcoat

Substrate Compatibility

Primary Substrates	Coated paper, uncoated paper, synthetics, cold storage labels
Not Recommended For	High-abrasion industrial surfaces without over-lamination
Smudge Resistance	High — excellent resistance vs standard/excellent wax
Scratch Resistance	High — suitable for moderate handling environments

Storage & Environment

Operating Temperature	5°C – 35°C (41°F – 95°F)
Storage Temperature	-5°C – 40°C (23°F – 104°F)
Relative Humidity	20% – 80% RH (non-condensing)
Shelf Life	1 year from manufacture date (sealed)
Storage Condition	Cool, dry place away from direct sunlight

Compliance

RoHS	Compliant
REACH	Compliant
Heavy Metals	Free from regulated heavy metals

Application

Description

Experience top-tier performance with JPN680, the premium enhanced wax ribbon tailored to meet the exacting standards of diverse industries. Boasting a low printing temperature and robust scratch resistance, JPN680 ensures durability and energy efficiency. outstanding scratch resistance, coupled with low printing energy consumption and superior printing quality, positions it as the ideal solution across various fields. This cost-effective enhanced wax ribbon excels in substrate compatibility and offers exceptional sensitivity and definition, making it the perfect choice for general-purpose applications. JPN680 outshines its counterparts, printing at lower energy settings, creating darker images, and delivering heightened durability, with a capacity exceeding 3 million linear inches.
