JPN780

JPN780

Made in Japan

Download Full Datasheet JPN780-Premium-Wax-Resin-1.pdf

THERMAL TRANSFER RIBBON Premium Wax-Resin

JPN780 Premium Wax-Resin

An excellent-grade premium wax-resin ribbon delivering outstanding print quality with superior scratch, smudge, and chemical resistance on a wide range of paper and synthetic substrates.

• Engineered specifically for flat-head thermal printheads with optimal energy transfer
• High-speed printing up to 10 IPS with deep black density
• Excellent scratch, smudge, and chemical resistance exceeding standard wax-resin
• Outstanding edge definition for crisp, scannable barcodes and fine text
• Versatile on coated paper, synthetics, PET, and matte labels

Ink Type Wax-Resin

Max Speed 10 IPS

Length 300 m

Core Size 1″ / 0.5″

Width Range 25–220 mm

Backcoat Anti-static

Recommended Substrates

Coated Paper Matte Paper Synthetic Paper PET Labels PP/PE Films

Typical Applications

Shipping Labels

Industrial Labels

Outdoor Labels

Cold Storage

Compatible Printers

Zebra Sato TSC Datamax Intermec Honeywell Godex + More

Quantity (rolls):

− +

Enter quantity and request a quote for pricing.

Request Quote Spec Sheet

View Full Specifications

General Information

Product Code	JPN780
Ink Type	Premium Wax-Resin
Color	Black
Brand	Wintech
Origin	Made in Japan

Ribbon Specifications

Width Available	25, 33, 40, 50, 55, 60, 80, 90, 100, 110, 130, 150, 160, 170, 220 mm
Length	300 m
Core Size	1 inch (25.4 mm) / 0.5 inch (12.7 mm)
Winding Direction	Coated Side Out (CSO) / Coated Side In (CSI)
Ink Side	Outside (standard) / Inside (available on request)
Printhead Type	Flat Head (Corner Edge)

Print Performance

Max Print Speed	10 IPS (254 mm/s)
Recommended Speed	2–8 IPS for optimal quality
Print Quality	Deep black density with sharp edge definition
Smudge Resistance	Excellent — superior to standard wax-resin ribbons
Scratch Resistance	Excellent — suitable for high-handling environments
Chemical Resistance	Excellent — resistant to solvents, oils, and water
Heat Resistance	Excellent — withstands elevated temperatures
Static Control	Anti-static backcoat

Substrate Compatibility

Primary Substrates	Coated paper, matte paper, synthetic paper, PET, PP, PE, glossy paper
Also Suitable For	Kimdura, Tyvek, coated tags and board stock
Not Recommended For	Harsh chemical exposure without over-lamination (use full resin); uncoated cardboard (use wax for cost-efficiency)

Storage & Environment

Operating Temperature	5°C – 35°C (41°F – 95°F)
Storage Temperature	-5°C – 40°C (23°F – 104°F)
Relative Humidity	20% – 80% RH (non-condensing)
Shelf Life	1 year from manufacture date (sealed)
Storage Condition	Cool, dry place away from direct sunlight

Compliance

RoHS	Compliant
REACH	Compliant
Heavy Metals	Free from regulated heavy metals

Application

Description

JPN780 delivers exceptional performance for harsh environments and demanding applications. This wax/resin formulation prints deep black, high-resolution barcodes and variable information with razor-sharp clarity and edge definition. Its exceptional scratch and smudge resistance ensures printed images remain pristine, while eliminating label retrack issues during printing. JPN780 excels on a wide range of receiving materials, including coated and uncoated paper labels and tags, varnished label stock, and even flood-coat substrates, making it the ideal choice for extreme printing applications.
